AD7890ARZ-10

AD7890ARZ-10
Mfr. #:
AD7890ARZ-10
Manufacturer:
Analog Devices Inc.
Description:
Analog to Digital Converters - ADC LC2MOS 8CH 12B Data Acquisition System
Lifecycle:
New from this manufacturer.
Datasheet:
AD7890ARZ-10 Datasheet
Delivery:
DHL FedEx Ups TNT EMS
Payment:
T/T Paypal Visa MoneyGram Western Union
HTML Datasheet:
AD7890ARZ-10 DatasheetAD7890ARZ-10 Datasheet (P4-P6)AD7890ARZ-10 Datasheet (P7-P9)AD7890ARZ-10 Datasheet (P10-P12)AD7890ARZ-10 Datasheet (P13-P15)AD7890ARZ-10 Datasheet (P16-P18)AD7890ARZ-10 Datasheet (P19-P21)AD7890ARZ-10 Datasheet (P22-P24)AD7890ARZ-10 Datasheet (P25-P27)AD7890ARZ-10 Datasheet (P28-P29)
ECAD Model:
More Information:
AD7890ARZ-10 more Information AD7890ARZ-10 Product Details
Product Attribute
Attribute Value
Manufacturer:
Analog Devices Inc.
Product Category:
Analog to Digital Converters - ADC
RoHS:
Y
Series:
AD7890
Mounting Style:
SMD/SMT
Package / Case:
SOIC-24
Resolution:
12 bit
Number of Channels:
8 Channel
Sampling Rate:
117 kS/s
Input Type:
Single-Ended
Interface Type:
Serial
Architecture:
SAR
Reference Type:
External, Internal
Analog Supply Voltage:
5 V
Digital Supply Voltage:
5 V
SNR - Signal to Noise Ratio:
70 dB
Minimum Operating Temperature:
- 55 C
Maximum Operating Temperature:
+ 125 C
Packaging:
Tube
Height:
2.35 mm
Input Voltage:
+/- 10 V
Length:
15.6 mm
Number of Converters:
1 Converter
Output Type:
CMOS/TTL
Power Consumption:
30 mW
Type:
S/H ADC
Width:
7.6 mm
Brand:
Analog Devices
DNL - Differential Nonlinearity:
+/- 1 LSB
Gain Error:
+/- 2.5 LSB
INL - Integral Nonlinearity:
+/- 1 LSB
Moisture Sensitive:
Yes
Number of ADC Inputs:
8 Input
Operating Supply Voltage:
5 V
Pd - Power Dissipation:
50 mW
Product Type:
ADCs - Analog to Digital Converters
Sample and Hold:
Yes
Factory Pack Quantity:
31
Subcategory:
Data Converter ICs
Unit Weight:
0.038731 oz
Tags
AD7890ARZ, AD7890AR, AD7890A, AD7890, AD789, AD78, AD7
Service Guarantees

We guarantee 100% customer satisfaction.

Quality Guarantees

We provide 90-360 days warranty.

If the items you received were not in perfect quality, we would be responsible for your refund or replacement, but the items must be returned in their original condition.
Our experienced sales team and tech support team back our services to satisfy all our customers.

we buy and manage excess electronic components, including excess inventory identified for disposal.
Email us if you have excess stock to sell.

Email: info@omo-ic.com

Step1: Vacuum Packaging with PL
Step1:
Vacuum Packaging with PL
Step2: Anti-Static Bag
Step2:
Anti-Static Bag
Step3: Packaging Boxes
Step3:
Packaging Boxes
***ical
8-Channel Single ADC SAR 117ksps 12-bit Serial 24-Pin SOIC W Tube
***p One Stop Global
Single ADC SAR 117ksps 12-bit Serial 24-Pin SOIC W
***Components
In a Tube of 31, Analog Devices AD7890ARZ-10, 12-bit Serial ADC, 24-Pin SOIC W
***ark
Analogue to Digital Converter, 12 bit, 117 kSPS, Single, 4.75 V, 5.25 V, MSOP RoHS Compliant: Yes
*** Source Electronics
IC DAS 12BIT 8CH 24-SOIC
***i-Key
IC DAS 12BIT 117K 24SOIC
***hardson RFPD
CONVERTER - ADC
***ment14 APAC
Prices include import duty and tax. IC, 12BIT DAS, SMD, 7890, SOIC24; Resolution (Bits):12bit; Sampling Rate:117kSPS; Input Channel Type:Single Ended; Data Interface:Serial; Supply Voltage Type:Single; Supply Voltage Min:4.75V; Supply Voltage Max:5.25V; ADC / DAC Case Style:MSOP; No. of Pins:24Pins; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Product Range:Octal 12-Bit SAR ADCs; Automotive Qualification Standard:-; MSL:MSL 3 - 168 hours; SVHC:No SVHC (07-Jul-2017); Base Number:7890; Conversion Time:5.9µs; IC Case Style:SOIC; IC Generic Number:7890; IC Temperature Range:Commercial; Linearity Error:1%; Linearity Error ADC / DAC +:1LSB; Linearity Error ADC / DAC -:1LSB; Logic Function Number:7890; No. of Bits:12bit; No. of Channels:8Channels; Operating Temperature Range:-40°C to +85°C; Supply Current:10mA; Supply Voltage Range:4.75V to 5.25V; Supply Voltage Range - Analogue:4.75V to 5.25V
***nell
IC, 12BIT DAS, SMD, 7890, SOIC24; Risoluzione (Bit):12bit; Frequenza di Campionamento:117kSPS; Tipo di Canale di Ingresso:Single Ended; Interfaccia Dati:Seriale; Tipo di Tensione di Alimentazione:Singola; Tensione di Alimentazione Min:4.75V; Tensione di Alimentazione Max:5.25V; Modello Case ADC/DAC:MSOP; No. di Pin:24Pin; Temperatura di Esercizio Min:-40°C; Temperatura di Esercizio Max:85°C; Gamma Prodotti:Octal 12-Bit SAR ADCs; Standard di Qualifica Automotive:-; Livello di Sensibilità all'Umidità (MSL):MSL 3 - 168 ore; Sostanze Estremamente Preoccupanti (SVHC):No SVHC (07-Jul-2017); Corrente di Alimentazione:10mA; Errore di Linearità:1%; Errore di Linearità ADC/DAC +:1LSB; Errore di Linearità ADC/DAC -:1LSB; Intervallo Temperatura CI:Commerciale; Intervallo Temperatura di Esercizio:Da -40°C a +85°C; Intervallo Tensione Alimentazione - Analogica:Da 4,75V a 5,25V; Intervallo Tensione di Alimentazione:Da 4,75V a 5,25V; Modello Case CI:SOIC; No. di Bit:12bit; No. di Canali:8Canali; Numero Base:7890
***log Devices
The AD7890 is an 8-channel 12-bit data acquisition system. The part contains an input multiplexer, an on-chip track/hold amplifier, a high speed 12-bit ADC, a 2.5 V reference, and a high speed, serial interface. The part operates from a single 5 V supply and accepts an analog input range of ±10 V (AD7890-10), 0 V to 4.096 V (AD7890-4), and 0 V to 2.5 V (AD7890-2). The multiplexer on the part is independently accessible. This allows the user to insert an antialiasing filter or signal conditioning, if required, between the multiplexer and the ADC. This means that one antialiasing filter can be used for all eight channels. Connection of an external capacitor allows the user to adjust the time given to the multiplexer settling to include any external delays in the filter or signal conditioning circuitry. Output data from the AD7890 is provided via a high speed bidirectional serial interface port. The part contains an on-chip control register, allowing control of channel selection, conversion start, and power-down via the serial port. Versatile, high speed logic ensures easy interfacing to serial ports on microcontrollers and digital signal processors. In addition to the traditional dc accuracy specifications such as linearity, full-scale, and offset errors, the AD7890 is also specified for dynamic performance parameters including harmonic distortion and signal-to-noise ratio. Power dissipation in normal mode is low at 30 mW typical and the part can be placed in a standby (power-down) mode if it is not required to perform conversions. The AD7890 is fabricated in Analog Devices, Inc.'s Linear Compatible CMOS (LC2MOS) process, a mixed technology process that combines precision bipolar circuits with low power CMOS logic. The part is available in a 24-lead, 0.3" wide, plastic or ceramic dual-in-line package or in a 24-lead small outline package (SOIC_W). Product Highlights Complete 12-Bit Data Acquisition System-on-a-Chip. The AD7890 is a complete monolithic ADC combining an 8-channel multiplexer, 12-bit ADC, 2.5 V reference, and a track/hold amplifier on a single chip. Separate Access to Multiplexer and ADC. The AD7890 provides access to the output of the multiplexer allowing one antialiasing filter for 8 channels—a considerable savings over the 8 antialiasing filters required if the multiplexer is internally connected to the ADC. High Speed Serial Interface. The part provides a high speed serial interface for easy connection to serial ports of microcontrollers and DSP processors.
Analog Devices Instrumentation & Measurement
In systems such as analytical or environmental monitoring instruments, an accurate and stable signal chain is required. By offering superior performance, including high precision, as well as low drift over both temperature and time, ADI's components allow designers to meet the specifications their customers demand. In addition, ADI's broad product portfolio for analytical test and measurement instrumentation systems provides the designer with an array of complementary components for the complete signal chain - from sensor to bits - to minimize the development effort and time required. Bookmark this page for the latest information on ADI's Instrumentation solutions offered through Mouser.Learn More
