HS15 560R J

HS15 560R J
Mfr. #:
HS15 560R J
Manufacturer:
ARCOL / Ohmite
Description:
Wirewound Resistors - Chassis Mount 15W 560 Ohms 5%
Lifecycle:
New from this manufacturer.
Datasheet:
HS15 560R J Datasheet
Delivery:
DHL FedEx Ups TNT EMS
Payment:
T/T Paypal Visa MoneyGram Western Union
HTML Datasheet:
HS15 560R J Datasheet
ECAD Model:
Product Attribute
Attribute Value
Manufacturer:
Ohmite
Product Category:
Wirewound Resistors - Chassis Mount
RoHS:
Y
Series:
HS
Resistance:
560 Ohms
Power Rating:
15 W
Tolerance:
5 %
Temperature Coefficient:
100 PPM / C
Maximum Operating Temperature:
+ 200 C
Length:
19.9 mm
Width:
11.2 mm
Height:
11 mm
Packaging:
Bulk
Features:
Aluminum Housed Resistors
Operating Temperature Range:
-
Technology:
Wirewound
Termination Style:
Solder Lug
Brand:
ARCOL / Ohmite
Mounting Style:
Chassis Mount
Product Type:
Wirewound Resistors
Factory Pack Quantity:
200
Subcategory:
Resistors
Part # Aliases:
5% 560R HS15
Unit Weight:
0.246918 oz
