AMIS30542C5421RG

Mfr. #:: AMIS30542C5421RG
Manufacturer:: ON Semiconductor
Description:: IC MTRDRV BIPLR 4.75-5.25V 32QFP
Lifecycle:: New from this manufacturer.
Datasheet:: AMIS30542C5421RG Datasheet
Delivery:: DHL FedEx Ups TNT EMS
Payment:: T/T Paypal Visa MoneyGram Western Union
ECAD Model:

Product Attribute
Attribute Value

Manufacturer: ON Semiconductor

Product Category: PMIC - Motor Drivers, Controllers

Series: -

Packaging: Tape & Reel (TR)

Package-Case: 32-VQFN Exposed Pad

Technology: Power MOSFET

Operating-Temperature: -40°C ~ 172°C (TJ)

Mounting-Type: Surface Mount

Function: Driver - Fully Integrated, Control and Power Stage

Applications: General Purpose

Interface: SPI

Voltage-Supply: 4.75 V ~ 5.25 V

Supplier-Device-Package: 32-NQFP (7x7)

Current-Output: 2.2A

Output-Configuration: Half Bridge (4)

Voltage-Load: 6 V ~ 30 V

Motor-Type-Stepper: Bipolar

Motor-Type-AC-DC: -

Step-Resolution: 1 ~ 1/32
