ESDA7P120-1U1M

Mfr. #:: ESDA7P120-1U1M
Manufacturer:: STMicroelectronics
Description:: TVS Diodes / ESD Suppressors High-power transient voltage supressor (TVS)
Lifecycle:: New from this manufacturer.
Datasheet:: ESDA7P120-1U1M Datasheet
Delivery:: DHL FedEx Ups TNT EMS
Payment:: T/T Paypal Visa MoneyGram Western Union
ECAD Model:
More Information:: ESDA7P120-1U1M more Information ESDA7P120-1U1M Product Details

Product Attribute
Attribute Value

Manufacturer:: STMicroelectronics

Product Category:: TVS Diodes / ESD Suppressors

RoHS:: Y

Series:: ESDA7P120-1U1M

Product Type:: ESD Suppressors

Vesd - Voltage ESD Contact:: 30 kV

Vesd - Voltage ESD Air Gap:: 30 kV

Polarity:: Unidirectional

Number of Channels:: 1 Channel

Termination Style:: SMD/SMT

Breakdown Voltage:: 6.4 V

Working Voltage:: 5 V

Clamping Voltage:: 11.5 V

Ipp - Peak Pulse Current:: 120 A

Cd - Diode Capacitance:: -

Package / Case:: QFN 1610

Minimum Operating Temperature:: - 55 C

Maximum Operating Temperature:: + 150 C

Packaging:: Reel

Brand:: STMicroelectronics

Factory Pack Quantity:: 8000

Subcategory:: TVS Diodes / ESD Suppression Diodes

Tags: ESDA7, ESDA, ESD

Service Guarantees

We guarantee 100% customer satisfaction.

Quality Guarantees

We provide 90-360 days warranty.

If the items you received were not in perfect quality, we would be responsible for your refund or replacement, but the items must be returned in their original condition.
Our experienced sales team and tech support team back our services to satisfy all our customers.

we buy and manage excess electronic components, including excess inventory identified for disposal.
Email us if you have excess stock to sell.

Email: info@omo-ic.com

Step1:
Vacuum Packaging with PL

Step2:
Anti-Static Bag

Step3:
Packaging Boxes

ESDA7P120-1U1M Description

***et Europe: TVS Diode, SMD, ESD Array, 7V Typ, 120A, Unidirectional, QFN

***ical: ESD Suppressor TVS Uni-Dir 2-Pin Case 1610 T/R

***i-Key: TVS DIODE 5.5V 11.5V 1610

***ment14 APAC: ESD PROTECTION DIODE, QFN-2

***ark: Esd Protection Diode, Qfn-2; Clamping Voltage Vc Max:11.5V; Diode Case Style:qfn; No. Of Pins:2Pins; Operating Voltage:-; Power Dissipation Pd:-; Product Range:-; Automotive Qualification Standard:-; Svhc:no Svhc (15-Jan-2019); Rohs Compliant: Yes

ESDA7P120-1U1M More Information

Standard Products: STMicroelectronics Standard Products are a broad range of industry-standard and drop-in replacements for the most popular general-purpose analog ICs, discrete and serial EEPROMs. The Standard Products are manufactured to the highest quality standards with many AECQ-qualified for automotive applications. A comprehensive set of design aids, including SPICE, IBIS models and simulation tools, are available to make adding to a design-in easy.
