Housing-HC-HPR-B10-HHWH-1TTM32-EM-BK-1411067
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
HEAVYCON B10 sleeve housing, HPR series, with screw locking, with M32 thread, straight outlet, for
increased environmental and EMC requirements
Why buy this product
Vibration and shock: IEC 61373/EN 50155, category 1, class 1B
Key Commercial Data
Packing unit 1 STK
GTIN
GTIN 4046356921503
Technical data
Dimensions
Height 100.5 mm
Width 58 mm
Length 145 mm
Ambient conditions
Degree of protection of housing (IP) IP66
IP68 (0.5bar / 24h)
IP69K (ISO20653:2013-02)
Ambient temperature (operation) -40 °C ... 125 °C
General
Note For contact inserts HC-B10, BB18, DD42, M, K8/24
Size B10
Housing type Sleeve housing
Color black
Locking type with screw locking
