APPLICATIONS INFORMATION

Current Limit

The LTC4274A/LTC4274C port includes two current limit-

ing thresholds (I

CUT

and I

LIM

), each with a corresponding

timer (t

CUT

and t

LIM

). Setting the I

CUT

and I

LIM

thresholds

depends on several factors: the class of the PD, the volt-

age of the main supply (V

), the type of PSE (Type 1 or

Type 2), the sense resistor (0.5Ω or 0.25Ω), the SOA of

the MOSFET, and whether or not the system is required

to implement class enforcement.

Per the IEEE specification, the LTC4274A/LTC4274C will

allow the port current to exceed I

CUT

for a limited period

of time before removing power from the port, whereas it

will actively control the MOSFET gate drive to keep the port

current below I

LIM

. The port does not take any action to

limit the current when only the I

CUT

threshold is exceeded,

but does start the t

CUT

timer. If the current drops below

the I

CUT

current threshold before its timer expires, the

CUT

timer counts back down, but at 1/16 the rate that it

counts up. If the t

CUT

timer reaches 60ms (typical) the

port is turned off and the port t

CUT

fault is set. This allows

the current limit circuitry to tolerate intermittent overload

signals with duty cycles below about 6%; longer duty cycle

overloads will turn the port off.

The I

LIM

current limiting circuit is always enabled and

actively limiting port current. The t

LIM

timer is enabled

only when the programmable t

LIM

field is non-zero. This

allows t

LIM

to be set to a shorter value than t

CUT

to provide

more aggressive MOSFET protection and turn off a port

before MOSFET damage can occur. The t

LIM

timer starts

when the I

LIM

threshold is exceeded. When the t

LIM

timer

reaches 1.7ms (typ) times the programmable t

LIM

field the

port is turned off and the port t

LIM

fault is set. When the

LIM

field is zero, t

LIM

behaviors are tracked by the t

CUT

timer, which counts up during both I

LIM

and I

CUT

events.

CUT

is typically set to a lower value than I

LIM

to allow the

port to tolerate minor faults without current limiting.

Per the IEEE specification, the LTC4274A/LTC4274C will

automatically set I

LIM

to 425mA (shown in bold in Table 6)

during inrush at port turn-on, and then switch to the

programmed I

LIM

setting once inrush has completed.

To maintain IEEE compliance, I

LIM

should be kept at 425mA

for all Type 1 PDs, and 850mA if a Type 2 PD is detected.

LIM

is automatically reset to 425mA when a port turns off.

Table 6. Example Current Limit Settings

LIM

(mA)

INTERNAL REGISTER SETTING (hex)

SENSE

= 0.5Ω R

SENSE

= 0.25Ω

53 88

106 08 88

159 89

213 80 08

266 8A

319 09 89

372 8B

425 00 80

478 8E

531 92 8A

584 CB

638 10 90

744 D2 9A

850 40 C0

956 4A CA

1063 50 D0

1169 5A DA

1275 60 E0

1488 52 49

1700 40

1913 4A

2125 50

2338 5A

2550 60

2975 52

LIM

Foldback

The LTC4274A/LTC4274C features a two-stage foldback

circuit that reduces the port current if the port voltage falls

below the normal operating voltage. This keeps MOSFET

power dissipation at safe levels for typical 802.3af MOS-

FETs, even at extended 802.3at power levels. Current limit

and foldback behavior are programmable. Table 6 gives

examples of recommended I

LIM

LTC4274A/LTC4274C

4274acfd

For more information www.linear.com/LTC4274A

APPLICATIONS INFORMATION

The LTC4274A/LTC4274C will support current levels well

beyond the maximum values in the 802.3at specification.

The shaded areas in Table 6 indicate settings that may

require a larger external MOSFET, additional heat sinking,

or enabling t

LIM

MOSFET Fault Detection

The LTC4274A/LTC4274C PSE port is designed to toler-

ate significant levels of abuse, but in extreme cases it is

possible for the external MOSFET to be damaged. A failed

MOSFET may short source to drain, which will make the

port appear to be on when it should be off; this condition

may also cause the sense resistor to fuse open, turning

off the port but causing the LTC4274A/LTC4274C SENSE

pin to rise to an abnormally high voltage. A failed MOSFET

may also short from gate to drain, causing the LTC4274A/

LTC4274C GATE pin to rise to an abnormally high voltage.

The LTC4274A/LTC4274C OUT, SENSE and GATE pins

are designed to tolerate up to 80V faults without damage.

If the LTC4274A/LTC4274C sees any of these conditions

for more than 180μs, it disables all port functionality,

reduces the gate drive pull-down current for the port and

reports a FET Bad fault. This is typically a permanent fault,

but the host can attempt to recover by resetting the port,

or by resetting the entire chip if a port reset fails to clear

the fault. If the MOSFET is in fact bad, the fault will quickly

return, and the port will disable itself again.

An open or missing MOSFET will not trigger a FET Bad fault,

but will cause a t

START

fault if the LTC4274A/LTC4274C

attempts to turn on the port.

Voltage and Current Readback

The LTC4274A/LTC4274C measures the output voltage

and current at the port with an internal A/D converter.

Port data is only valid when the port power is on. The

converter has two modes:

• Slow mode: 14 samples per second, 14.5 bits resolution

• Fast mode: 440 samples per second, 9.5 bits resolution

In fast mode, the least significant 5 bits of the lower byte

are zeroes so that bit scaling is the same in both modes.

Disconnect

The LTC4274A/LTC4274C monitors the port to make

sure that the PD continues to draw the minimum speci-

fied current. A disconnect timer counts up whenever port

current is below 7.5mA (typ), indicating that the PD has

been disconnected. If the t

DIS

timer expires, the port will

be turned off and the disconnect bit in the fault event reg-

ister will be set. If the current returns before the t

DIS

timer

runs out, the timer resets and will start counting from the

beginning if the undercurrent condition returns. As long

as the PD exceeds the minimum current level more often

than t

DIS

, it will stay powered.

Although not recommended, the DC disconnect feature

can be disabled by clearing the DC Disconnect Enable

bit. Note that this defeats the protection mechanisms

built into the IEEE spec, since a powered port will stay

powered after the PD is removed. If the still-powered port

is subsequently connected to a non-PoE data device, the

device may be damaged.

The LTC4274A/LTC4274C does not include AC discon-

nect circuitry, but includes an AC Disconnect Enable bit

to maintain compatibility with the LTC4259A. If the AC

Disconnect Enable bit is set, DC disconnect will be used.

Shutdown Pin

The LTC4274A/LTC4274C includes a hardware SHDN pin.

When the SHDN pin is pulled to DGND, the port will be

shut off immediately. The port remains shut down until

re-enabled via I

C or a device reset in AUTO pin mode.

Masked Shutdown

The LTC4274A/

LTC4274C provides a low latency port

shedding feature to quickly reduce the system load when

required. By allowing a pre-determined set of ports to

be turned off, the current on an overloaded main power

supply can be reduced rapidly while keeping high priority

devices powered. Each port can be configured to high or

low priority; all low-priority ports will shut down within

6.5μs after the MSD pin is pulled low. If a port is turned off

via MSD, the corresponding Detection and Classification

Enable bits are cleared, so the port will remain off until

the host explicitly re-enables detection.

LTC4274A/LTC4274C

4274acfd

For more information www.linear.com/LTC4274A

SERIAL DIGITAL INTERFACE

Overview

The LTC4274A/LTC4274C communicates with the host us-

ing a standard SMBus/I

C 2-wire interface. The LTC4274A/

LTC4274C is a slave-only device, and communicates

with the host master using the standard SMBus proto-

cols. Interrupts are signaled to the host via the INT pin.

The timing diagrams (Figures 5 through 9) show typical

communication waveforms and their timing relationships.

More information about the SMBus data protocols can be

found at www.smbus.org.

The LTC4274A/LTC4274C requires both the V

and V

supply rails to be present for the serial interface to function.

Bus Addressing

The LTC4274A/LTC4274C’s primary serial bus address

is 010xxxxb, with the lower four bits set by the AD3-AD0

pins; this allows up to 16 LTC4274A/LTC4274Cs on a

single bus. All LTC4274A/LTC4274Cs also respond to

the address 0110000b, allowing the host to write the

same command (typically configuration commands) to

multiple LTC4274A/LTC4274Cs in a single transaction. If

the

LTC4274A/LTC4274C is asserting the INT pin, it will

also respond to the alert response address (0001100b)

per the SMBus spec.

Interrupts and SMBALERT

Most LTC4274A/LTC4274C port events can be configured

to trigger an interrupt, asserting the INT pin and alerting

the host to the event. This removes the need for the host

to poll the LTC4274A/LTC4274C, minimizing serial bus

traffic and conserving host CPU cycles. Multiple LTC4274A/

LTC4274Cs can share a common INT line, with the host

using the SMBALERT protocol (ARA) to determine which

LTC4274A/LTC4274C caused an interrupt.

For information on serial bus usage and device configura-

tion and status, refer to the LTC4274A/LTC4274C Software

Programming documentation.

EXTERNAL COMPONENT SELECTION

Power Supplies and Bypassing

The LTC4274A/LTC4274C requires two supply voltages to

operate. V

requires 3.3V (nominally) relative to DGND.

requires a negative voltage of between –45V and –57V

for Type

1 PSEs, –51V to –57V for Type 2 PSEs or –54.75V

to –57V for LTPoE

PSEs, relative to AGND. The relation-

ship between the two grounds is not fixed; AGND can be

referenced to any level from V

to DGND, although it

should typically be tied to either V

or DGND.

provides power for most of the internal LTC4274A/

LTC4274C circuitry, and draws a maximum of 3mA. A

ceramic decoupling cap of at least 0.1μF should be placed

from V

to DGND, as close as practical to each LTC4274A/

LTC4274C chip.

Figure 14 shows a three component low dropout regula-

tor for a negative supply to DGND generated from the

negative V

supply. V

is tied to AGND and DGND is

negative referenced to AGND. This regulator drives a single

LTC4274A/LTC4274C device. In Figure 15, DGND is tied

to AGND in this boost converter circuit for a positive V

supply of 3.3V above AGND. This circuit can drive multiple

LTC4274A/LTC4274C devices and opto couplers.

is the main supply that provides power to the PD.

Because it supplies a relatively large amount of power and

is subject to significant current transients, it requires more

design care than a simple logic supply. For minimum IR

loss and best system efficiency, set V

near maximum

amplitude (57V), leaving enough margin to account for

transient over- or undershoot, temperature drift, and the

line regulation specs of the particular power supply used.

APPLICATIONS INFORMATION

Figure 14. Negative LDO to DGND

4274AC F14

750k

CMHZ4687-4.3V

0.1µF

CMPTA92

LTC4274AC

AGND

DGND

10Ω

SMAJ58A

1µF

100V

P1-P3 P4-P6 P7-P9 P10-P12 P13-P15 P16-P18 P19-P21 P22-P24 P25-P27 P28-P30

LTC4274AIUHF-4#PBF

Mfr. #:

Buy LTC4274AIUHF-4#PBF

Manufacturer:

Analog Devices Inc.

Description:

Power Switch ICs - POE / LAN LTPoE++ 90W Single Powered Ethernet PSE

Lifecycle:

New from this manufacturer.

Delivery:

DHL FedEx Ups TNT EMS

Payment:

T/T Paypal Visa MoneyGram Western Union

LTC4274AIUHF-4#PBF

LTC4274AIUHF-4#PBF

Products related to this Datasheet
